10HP 3PH Dust Collection Blower
10HP 3PH Dust Collection Blower
Regular price
$3,519.00
Regular price
Sale price
$3,519.00
Unit price
per
Exact shipping calculated after quote submission.
Our dust blowers are made up of a heavy duty dynamically balanced vaneaxial fan with safety guards on all inlets. The steel impeller is mounted directly to the shaft of the stand-mounted motor. Motors are available from 5 to 25 horsepower, 3 phase electric and have options for magnetic starters and remote control. Single phase electric motors are available for blowers up to 7.5 horsepower. Magnetic starter included.
Model: DB-100
Couldn't load pickup availability
| 10HP 3PH Dust Collection Blower | 15HP 3PH Dust Collection Blower, 7900CFM | 20HP 3PH Dust Blower | 25HP 3PH Dust Blower | 5HP 3PH Dust Blower | 7.5HP 3PH Dust Blower | |
|---|---|---|---|---|---|---|
| Amps | 27A @ 220V | 37A @ 220V | 49A @ 220V | 60A @ 220V | 1PH: 27A @ 220V 3PH: 17A @ 220V | 1PH: 38A @ 220V 3PH: 20A @ 220V |
| Cfm | 6350 | 7900 | 8375 | 10350 | 3200 | 4700 |
| Fan rpm | 3450 | 1725 | 1725 | 1725 | 3450 | 3450 |
| Fan size | 14" | 25" | 26" | 27" | 13" | 13.5" |
| Horsepower | 10HP | 15HP | 20HP | 25HP | 5HP | 7.5HP |
| Inlet-size | 12" | 14" | 16" | 18" | 10" | 12" |
| Outlet size | 14" | 16" | 18" | 20" | 12" | 14" |
| Phase | 3 | 3 | 3 | 3 | 1 or 3 | 1 or 3 |
| Weight | 360 lbs | 750 lbs | 810 lbs | 850 lbs | 280 lbs | 330lbs |
